| Welding Type | Amps@Rated Duty Cycle |
| TIG | 280A @ 60% |
| 250A @ 100% | |
| 325A @ 40% | |
| Stick | 220A 60% |
| 250A 40% | |
| 180A 100% |
| Parameter | TIG325X |
| Max Inrush (I1MAX) Amps | 120v 25.3A(TIG) 42.5A (STICK) |
| 240v 53.3A (TIG) 53.5(STICK) | |
| Max Rated (I1eff) Amps | 120v 15.1A(TIG) 26.5A(STICK) |
| 240v 35.7A(TIG) 34.9(STICK) | |
| OCV | TIG 75V |
| STICK 75V | |
| TIG Output range DC | 5-325A/ 10.2v-23v |
| TIG Output range AC | 10-325A/ 10.4v-23v |
| Stick Output rang DC | 20-250A/ 20.8-30v |
| Stick Hot Start Amps | 0-50A |
| Stick Arc Force Amps | 0-100A |
| Stick Hot Start | Adjustable |
| Stick E6010/ Cellulose setting or capablity | YES |
| Minimum TIG Amps DC | 5A |
| Minimum TIG Amps AC | 10A |
| TIG Start Type | HF |
| Memory | NO |
| TIG Start Amps Range | 5-325A |
| End Amps Range | 5-325A |
| TIG Upslope Time | 0-15s |
| Downslope Time | 0-25s |
| Pre flow time | 0.1-3s |
| Post flow time | 0-15s |
| TIG Pulse | yes |
| TIG Pulse Frequency ( Pulses per second) DC | 0.5-200HZ |
| TIG Pulse Frequency ( Pulses per second) AC | 0.5-200HZ |
| TIG Pulse Time On | 10-90% |
| TIG Pulse Amp Range ( Base Amps %) | 5-95% |
| TIG AC Frequency | 20-300HZ |
| TIG AC Balance | 20-80% |
| TIG AC Wave Form | Adv. Square |
| Remote Control | 2T/4T |
| Foot pedal | Standard |
| Machine alone size | 23.27*11.34*19.13inches |
| Machine Weight | 73.24lb |
| Power cable length | 86.61inches |
