*Water cooler
required (click here) for use withCK18 and CK20 torches
Specifications
- Input Voltage:
120V / 240V, single-phase, 50/60 Hz
- Output Range:
TIG 10–225A / Stick 10–180A
- Duty Cycle (TIG):
40% @ max output, 100% at 108A (120V) / 155A (240V)
- Duty Cycle
(Stick): 40% @ max output, 100% at 76A (120V) /
139A (240V)
- Pulse Frequency:
0.5–200 Hz (Low: 0.5–10 Hz, High: 10–200
Hz)
- AC Balance:
10–90%
- AC Frequency:
40–200 Hz
- Gas Flow
Settings: Pre-Flow 0.1–3 sec / Post-Flow
0–15 sec
- Weight:
41 lbs (18.5 kg)
- Dimensions:
20.5 × 11.8 × 21.5 in
- Warranty:
3-Year No-Hassle
